Chengli ISUZU HOWO Spider Wrecker Truck

- Truck brand: CLW
- Bed load:4 ton
- Winch:4 ton
- Engine:156HP
- Flatbed size:5400x2300mm
- Spider device: 4 ton, 5 ton capa
- Whatsapp/mob:+8618307220638
- Email:[email protected]
- Http://www.cnclwgroup.com
Description
Description

Road recovery wreckers, also known as called wrecker truck, road rescue truck, and tow trucks, have multiple functions such as lifting, pulling and lifting. The wreckers are mainly used for road failure vehicles, urban illegal vehicles and emergency rescue. CLW spider tow truck is used for loading, transportation and unloading of illegally parked or broken-down cars, SUV and smaller trucks.

【Chassis Parameters】

Cab chassis of Spider Wrecker Truck: (can also use ISUZU, FOTON, HOWO, SHACMAN, JAC, DONGFEN, etc)
CLW 4x2 cab chassis, single wide cab, condition new, 3 seats, 4400mm wheelbase, Yunnei D30TCIE1 156HP Euro5 dieseI engine, manual 6-speed transmission, 8.25R20 radial tires, with one spare tire, 2.7 ton front axle, 7.2 ton rear axle, air brake, abs, engine brake, power assist steering, with air conditioning, etc.
spider tow truck 4 ton lift away spider towing truck spider wrecker truck

【Upper Structure Parameters】

Upper body of CLW 4x2 4 ton spider wrecker truck with spider crane
4 tons bed carry capacity,  4 tons hydraulic winch, 25m steel rope; flatbed length 5.4 meters, width 2.3 meters; double side linkage operation; full hydraulic folding tailplate; one set(2 pcs) auxiliary wheeler, 4 pcs tight strips, engineering long light with siren, louder speaker,etc.
Spider crane for car lifting: with 4 pieces of tire irons, with chain and fasteners, the spider can rotary 360 degree, and it can hydraulic rotary and sliding adjust its position.



Chassis manufactory Chengli Special Automobile Co.,Ltd
Spider system manufactory Chengli Special Automobile Co.,Ltd
Chassis brand CLW
Whole truck model

CLW5110TQZCL5

Chassis model CL1100D1V
Spider system moel QZ04T04J
Steering wheel location Left(factory)
Date of issue 2024
Steering gear Left, with amplifier
Engine Diesel, 2.977L, 156hp
Cylinders 4
Overall dimension 8560x2350x3250mm
Gearbox Manual, 6+1(6Front and 1Rear)
Emission Euro5
Calculation formula 4x2
Wheelbase 4400 mm
Cabin type 1+2 seats
Rear suspension Leaf spring type
Fuel tank capacity 120 liters
Gross weight(kg) 11995 kg
Truck load capacity 4000 kg
Brake system ABS/pneumatic
Power tank off mechanism(PTO) mounted on the gearbox
Tire irons 4 pieces of tire irons, with chain and fasteners
Other Cab heater - air conditioning
platform of spider tow truck
Type Moving platform
Platform length 5400 mm
Platform width 2300 mm
Safety supports at the rear rear mounted vertical
Safety supports in the front H type(horizontal - vertical) installed in front of the platform
Turning angle Crane can rotary 360°, spider can rotary 360°
Control panel is standing 1 set
Spider mechanism Yes
Hydraulic spider capacity 4000 kg
Accessories of wrecker truck spider
1 A yellow flashing light mounted on top of the cab
2 Cargo compartment lighting
3 audio system (radio,mp3)
4 Toolbox
5 Spare tire with clamp 1 (one) piece
6 Rear wheel mudguards (protectors)
7 Wheel fasteners on the platform at least 2 (two) pieces
8 Hydraulic domcrat
9 tire wrench
10 A set of wrenches required for maintenance
11 First aid kit
12 fire extinguisher

More Reference Pictures of CLW 4x2 4 ton spider wrecker truck with spider crane:
spider tow truck 4 ton lift away spider towing truck spider wrecker truckCLW spider tow truck is a kind of wrecker tow truck, used for loading, transportation, and unloading of illegally parked cars, or broken down cars, SUV and small trucks.
spider tow truck 4 ton lift away spider towing truck spider wrecker truckWrecker tow truck spider with a special lifting device that can lift cars without damaged cars, with a perfect way to lift way, so very popular in Europe and police use.
spider tow truck 4 ton lift away spider towing truck spider wrecker truckCompared with traditional way to use a crane and rope to lift cars, spider tow truck is better and convenience to use.
Chengli CLW 4x2 4 ton flatbed wrecker tow truck
The Crane Spider System Mechanism of CLW 4x2 4 ton spider wrecker truck with spider crane:

The type of Chengli CLW 4x2 4 ton spider flatbed wrecker tow truck with crane:

This is a one-tow-two cars wrecker flatbed tow truck, one car can be loaded on the flatbed tray, another is towed drag at rear of wrecker truck. The loading method and loading status of wrecker tow trucks carry car on flatbed:
The loading method and loading status of wrecker truck, by towed a fault car at rear of tow truck:
the rear of wrecker tow truck is with a hydraulic lifting tow boom, can extend and lift up down, can tow a car weight 2-3 tons.After fault car is on flatbed tray, how do we tighten the car?How to use the assisted wheeler?
