【Chassis Parameters】
Dongfeng cab chassis, condition new, single cabin, 3 seats, 3300mm wheelbase, Yunnei 90HP or Yuchai 120HP Euro 3 dieseI engine, manual 5-speed transmission, 7.00R16 radial tires, with one spare tire, 2 Ton front axle, 3.5 Ton rear axle, air brake, power assist steering, etc.
Chassis brand options: Dongfeng, Sinotruk HOWO, Foton, JAC, SHACMAN, SAIC-HONGYAN-IVECO, etc.
【Upper Structure Parameters】
- Insulation box size 4150x1900x1900mm, total 15 cubic meter box volume; insulation box material outer panel is FRP panel, middle with 80mm insulation layer, inside panel is stainless steel 304 sheet, stainless steel floor;
- Refrigeration unit is American import Thermo King -5℃ capacity.
- Refrigeration unit brand options: American import brand Thermo King, Carrier brand; China brand Hanxue, Kauxue, Huatai, Bingli, etc.
- Special Devices: refrigeration unit, ultraviolet disinfection lamp, disinfection spray nozzle, sewage tank, sealed door, etc.
| Model | CLW5070XLCYFD3 |
| Chassis brand | Dongfeng |
| Wheeldrive | 4x2, LHD |
| New or Used | New |
| Overall dimension(mm) | 5995x2200x2985 |
| Insulation box dimension(mm) | 4150x2000x2000 |
| Material of Insulation box | Sanwitch structure: FRP panel + 80mm insulation + Stainless Steel 304 |
| Refrigeration unit |
-5℃ ~ 0℃ |
| Gross weight(kg) | 7360 |
| Curb weight(kg) | 2850 |
| Load Weight(kg) | 4-5 tons |
| Wheelbase(mm) | 3300 |
| Engine power | Yunnei 90HP or Yuchai 120 Euro3 |
| Fuel type | DieseI |
| Transmission | Manual 5- speed |
| Brake | Air brake |
| Axle load(front/rear) | 2/3.5 tons |
| Tire | 6+1 pcs, 7.00R16 radial tires |
| Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
