【Chassis Parameters】
Dongfeng DFAC Dolicar New cab chassis, condition new, 3 seats, 3800mm wheelbase, Yuchai 120HP Euro 3 dieseI engine, Manual 5-speed transmission, 7.50R16 radial tires, with one spare tire, 2.5 Ton front axle, 5 Ton rear axle, air brake, exhaust brake, power assist steering, etc.
Chassis brand options: Dongfeng, Sinotruk HOWO, Foton, JAC, SHACMAN, SAIC-HONGYAN-IVECO, etc.
【Upper Structure Parameters】
Insulation box size 5150x2150x2200mm, total 24.36 cbm box volume; insulation box material outer and inner plate are FRP panel, middle with 80mm insulation layer; Refrigeration unit is China brand -16℃ capacity.
Refrigeration unit brand options: American import brand Thermo King, Carrier brand; China brand Hanxue, Kauxue, Huatai, Bingli, etc.
| Model | CLW5090XLCD3 |
| Chassis brand | DongFeng |
| Wheeldrive | 4x2, LHD |
| New or Used | New |
| Overall dimension(mm) | 7000x2380x3350 |
| Insulation box dimension(mm) | 5150x2150x2200 |
| Material of Insulation box | Sanwitch structure: FRP panel + 80mm insulation + FRP panel |
| Refrigeration unit |
China famous brand -16℃~ 0 ℃ |
| Gross weight(kg) | 9850 |
| Curb weight(kg) | 4500 |
| Load Weight(kg) | 6~8 tons |
| Wheelbase(mm) | 3800 |
| Engine power | Yuchai 120HP Euro3 |
| Fuel type | DieseI |
| Transmission | Manual 5- speed |
| Brake | Air brake |
| Axle load(front/rear) | 2.5 tons / 5 tons |
| Tire | 6+1 pcs, 7.50R16 radial tires |
| Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
