【Chassis Parameters】
Dongfeng 4x2 chassis, RHD cabin, condition new, 3300mm wheelbase, Yunnei 90HP Euro3 diesel engine, manual 5-speed transmission, 7.00R16 radial tires, with one spare tire, 2 ton front axle, 4 ton rear axle, air brake, power assist steering, exhaust pipe front mounted, etc.
【Upper Structure Parameters】
Dump box size 3800x1900x800mm; dump box material 3mm side wall, 4mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.
| Model | CLW5071ZZXD3 |
| Chassis brand | Dongfeng |
| Wheeldrive | 4x2, RHD |
| New or Used | New |
| Overall dimension(mm) | 5995x2050x2430 |
| Dump box dimension(mm) | 3800x1900x800 |
| Material of dump box | carbon steel, 3mm side, 4mm floor |
| Unloading method of dump box |
middle double cylinder lifting jack |
| Gross weight(kg) | 7360 |
| Curb weight(kg) | 3800 |
| Load Weight(kg) | 4 tons |
| Wheelbase(mm) | 3300 |
| Engine power | Yunnei 90HP Euro3 |
| Fuel type | DieseI |
| Transmission | Manual 5- speed |
| Brake | Air brake |
| Axle load(front/rear) | 2 tons/4 tons |
| Tire | 6+1 pcs, 7.00R16 radial tires |
| Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
